No commentRuida DSP Co2 Laser Controller RDC6332G For Co2 Laser Cutting Machine (laser controller mainboard+ panel+ usb cable+ power cable)1. Technical Parameter:
1) The digital laser control signal
a) Differential output, TTL level, 20mA Driving ability
b) PWM frequency 2.5K ~ 100K for adjustable
c) PWM duty ratio 2% ~ 98% for adjustable
2) Analog laser control signal 0 ~ 5V automatically tracing adjust
3) Motor control signal differential output, TTL level, 20mA driving ability
4) Motor control pulse frequency maximum 500KHZ
5) USB maximum transmission rate 12M, the longest distance is 5 meters
6) Line/arc/B spline interpolation accuracy +/- 0.5 pulse
7) 4 –way general photoelectric isolation OC gate output, the maximum 600mA driving ability
8) 4 –way General photoelectric isolated input , TTL level
2. Specification:
| Model | RDC6332G | |
| Power Feature | Only one-way 24V (compatible with 36V for power supply, but not recommended) | |
| Laser Port Feature | Two-way digits and two-way analog port, settable independently and non-interacted | |
| USB Feature | Copying Speed | Very Quick |
| Compatibility | Support all USB disks with different capacities | |
| Memory Feature | Capacity | 256M |
| Fault Tolerance | Capable of checking defective track and formatting and good in fault tolerance | |
| General IO Feature | Input Port | 4 ways (two for general, two for specialties) |
| Output Port | 4-ways (500mA high current for each, OC output, two for general, two for specialties) | |
| Software Feature | Power-off restart for Engraving | YES |
| Multi-origin Logics | YES | |
| Parameter Backup Logics | YES | |
| Work time Preview | YES (the work time accurate to 1ms) | |
| Online Updata Mainboard Program | YES | |
| Display Feature | Online Modification Laser Power/Speed | YES |
| Offline Modification Layer parameters | YES | |
| Online Updata Startup Display | YES | |
| File dynamic/static preview | YES | |
| Modification Factory/User’s para on display | YES | |
| Display type | 320*240 TFT display | |
| Motion-axle Feature | Soft Spacing | YES |
| Hard Spacing | YES | |
| Copying Speed | Very Quick | |
| Compatibility | Support all USB disks with different capacities | |
| Capacity | 256M | |
| Fault Tolerance | Capable of checking defective track and formatting and good in fault tolerance | |
| Z-axle Linkage | YES | |
| Feeding Feature | Single/double direction for option | |
| Power-on Resetting | Configurable for each axes | |
| Key Speed | Configurable | |
| Encryption Feature | Realtime clock and battery integrated for hardware encryption | |
| Communicate Mode | 10/100MHZ Ethernet or USB2.0 | |
3. Application Materials:
RuiDa CO2 Laser Controller RDC6332G : all the Non-Metals and Painted Metals, Such as Acrylic, MDF, Double-Color board, Wood, Plywood, Cork, Bamboo, Plexiglas, Normal glass, Crystal, Plastic, Rubber, PVC board, Leather, Fabric, Paperboard, Granite, Marble, Tile, Foam, Ceramic, Corian, Delrin etc. , Leather, Decoration, Furniture, Advertisement, Packing and Printing, Molding and Art Craft Industries etc.
4. The Most Remarkable Characteristic :
1) The ethernet (10/100M) and the USB2.0 transmission (the transmission speed is above RDLC320-A product 3 times.);
2) The real color TFT screen, can demonstrate the real color on the kneading board the processing graph, simultaneously can on the kneading board the accurate learning laser processing coordinates position;
3) Can in advance look at the document graph on the kneading board which in the memory preserves, it brushes the screen speed, domestic manufacturer nobody can and;
4) Dynamic demonstration path processing advancement and fiducial mark;
5) Can in operate on the kneading board to revise each chart level directly the processing parameter (for example: The speed, the power and so on), after simultaneously can preserve automatically the revision chart level parameter, prepare the following use (this function other manufacturers to be unable to realize.);
6) Formidable mouse operation support.(Can directly carry on the operation in ours operation kneading board with the mouse, this function other manufacturers are unable to realize, simultaneously this function overseas customer likes extremely.);
7) The support power failure continues carves, the man-hour looks at in advance (as precisely as a millisecond level, the man-hour in advance looks at the value and the practical work consumes the time to be completely consistent, this function other manufacturers are unable to realize.)
8) Support feeding, fluctuation, revolving carving, about functions and so on push pedal.
9) The RDC6332G system is the RuiDa technology the technical development the newest generation of laser carving/cutting control system, this control system has the better hardware stability, has a better anti-high-pressured, the anti-electrostatic disturbance characteristic.
10) Based on the LINUX platform development man-machine operating system, has the friendlier operation contact surface and a more formidable function.
11) This controller use is more perfect the movement control algorithm which, optimizes, its processing speed and the efficiency are before the system is unable and.
5. Photos of RDC6332G :
