Laser Machine Best Choice Product provide laser cnc,laser engraving machine,laser machine,laser printer,laser wood machine Fast Promo MT-8013 800*1300mm XY Table and Co2 Laser Cutting Kit for Laser Machine Spare Parts. Price at this time US $1150.00/piece. Check price now to get discount! Dont waste your time. Buy Now only in Mactron Laser Parts Store Trusted Seller Store!
Single Head Laser Kits High Quality 8013 comes with: a laser head, mounts, and reduction gear for building a CO2 laser machine. Ideal for making a Pro shop commercial laser machine and an excellent candidate for DIY hobbyist. We provide a warranty to cover any defective parts within 1 years of your purchase!
1. Kit major part summary :
--- 5x 2" anodized aluminum base bars
--- 1x "X" slider & 2x "Y" slider
--- 2:1 reduction gear box for X & Y
--- 2x Leadshine 23 high torque3-phase 5A stepping motor
--- 2x 3DM583 stepping drive
--- 1x laser head for 25mm mirror and 20mm lens
--- 2x mirror mounts for 25mm mirror
--- 2x tube mounts
--- 2x limit switches
--- 4x 3-band axial coupling
--- 1x "X" slider track
--- 2x "Y" slider track
--- 2x stainless steel Y axial
2. Specification
--- Working area: 800mm x 1300mm (31" x 51")
--- Condition: New
--- Speed: X: 1000mm/s, Y: 550mm/s (with driver set to 1/32)
3. Specification of X motor:
--- Brand: Leadshine 3-phase
--- Step angle: 1.2 degree
--- Torque: 188oz-in
--- Current: 5.2A
--- Resistance: 0.9ohm
--- Inductance: 1.35mH
--- Detente torque: 700g
--- No. Wire: 6
--- Weight: 1.1Kg (2.4lb)
--- Length: 79mm
4. Specification of Y motor
--- Brand: Leadshine
--- Step angle: 1.2 degree
--- Torque: 188oz-in
--- Current: 5.2A
--- Resistance: 0.9ohm
--- Inductance: 1.35mH
--- Detente torque: 700g
--- No. Wire: 6
--- Weight: 1.1Kg (2.4lb)
--- Length: 79mm
5. Step Motor Driver : Leadshine 3DM580 or 3DM583
1) Extra-low motor noise offers excellent quietness
2) Anti-Resonance, provides optimum torque and nulls mid-range instability
3) Self-test and Auto-configuration technology, offers optimum responses with different motors
4) Microstep resolutions programmable, from full-step to 102,400 steps/rev
5) Supply voltage up to +60 VDC
6) Output current programmable, from 0.5A to 8.3A
7) Pulse input frequency up to 200 KHz
8) Automatic idle-current reduction
9) Supports PUL/DIR and CW/CCW modes
10) Suitable for 3/6 leads 3-phase motors
* This is a heavy duty Professional grade X-Y stages with sturdy aluminum base. It comes in 4 main pieces and basic assembly skill is required to set it up. Thats the beauty of doing DIY. Learn from hands on experience! Usually it take about 60~90min to assembly the job.
* The machine run fast, smooth and quiet with the 3-phase motor. Its ideal for making your DIY CO2 laser machine. Please note that you may need some hands on experience with basic electronic skill to make this project possible. The system is not just Plug & Play. Screw holes for mirror mounts, laser head are ready are pre-drilled. Limit switches for X & Y are installed.Enjoy building your CO2 machine! Were carrying other parts for building a laser machine. Laser tubes, laser power supply, DSP controller, water pumps, optical lens & mirrors.
Note: Pictures is showing an assembled unit. The unit you received is um-assembled kit.
