Mactron Laser Kits for Laser Cutting Machine comes with: a laser head, mounts, and reduction gear
for building a CO2 laser machine. Ideal for making a Pro shop commercial laser machine and an
excellent candidate for DIY hobbyist. We provide a warranty to cover any defective parts within 1
years of your purchase!
1. Kit major part summary :
--- 5x 2" anodized aluminum base bars
--- 1x "X" slider & 2x "Y" slider
--- 2:1 reduction gear box for X & Y
--- 2x Leadshine high torque3-phase stepping motor
--- 2x 3DM583 stepping drive
--- 1x laser head for 25mm mirror and 20mm lens
--- 2x mirror mounts for 25mm mirror
--- 2x tube mounts
--- 2x limit switches
--- 4x 3-band axial coupling
--- 1x "X" slider track
--- 2x "Y" slider track
--- 2x stainless steel Y axial
2. Specification
--- Working area: 1300mm x 900mm (51" x 35")
--- Condition: New
--- Speed: X: 1000mm/s, Y: 550mm/s (with driver set to 1/32)
3. Specification of X motor:
--- Brand: Leadshine 573S15 3-phase
--- Step angle: 1.2 degree
--- Torque: 188oz-in
--- Current: 5.2A
--- Resistance: 0.9ohm
--- Inductance: 1.35mH
--- Detente torque: 700g
--- No. Wire: 6
--- Weight: 1.1Kg (2.4lb)
--- Length: 79mm
4. Specification of Y motor
--- Brand: Leadshine 573S15
--- Step angle: 1.2 degree
--- Torque: 188oz-in
--- Current: 5.2A
--- Resistance: 0.9ohm
--- Inductance: 1.35mH
--- Detente torque: 700g
--- No. Wire: 6
--- Weight: 1.1Kg (2.4lb)
--- Length: 79mm
5. Step Motor Driver : Leadshine 3DM583
1) Extra-low motor noise offers excellent quietness
2) Anti-Resonance, provides optimum torque and nulls mid-range instability
3) Self-test and Auto-configuration technology, offers optimum responses with different motors
4) Microstep resolutions programmable, from full-step to 102,400 steps/rev
5) Supply voltage up to +60 VDC
6) Output current programmable, from 0.5A to 8.3A
7) Pulse input frequency up to 200 KHz
8) Automatic idle-current reduction
9) Supports PUL/DIR and CW/CCW modes
10) Suitable for 3/6 leads 3-phase motors
* This is a heavy duty Professional grade X-Y stages with sturdy aluminum base. It comes in 4 main
pieces and basic assembly skill is required to set it up. Thats the beauty of doing DIY. Learn from
hands on experience! Usually it take about 60~90min to assembly the job.
* The machine run fast, smooth and quiet with the 3-phase motor. Its ideal for making your DIY
CO2 laser machine. Please note that you may need some hands on experience with basic
electronic skill to make this project possible. The system is not just Plug & Play. Screw holes for
mirror mounts, laser head are ready are pre-drilled. Limit switches for X & Y are installed.Enjoy
building your CO2 machine! Were carrying other parts for building a laser machine. Laser tubes,
laser power supply, DSP controller, water pumps, optical lens & mirrors.
Note: Pictures is showing an assembled unit. The unit you received is um-assembled kit.
