Big Discount HY-T80 80w 220v /110v co2 laser power supply power source for 80w 1600mm tube laser engraving and cutting machine

Big Discount HY-T80 80w 220v /110v co2 laser power supply power source for 80w 1600mm tube laser engraving and cutting machine lamachine Rating: 3.9 out of 5

Laser Machine Best Choice Product provide laser cnc,laser engraving machine,laser machine,laser printer,laser wood machine Big Discount HY-T80 80w 220v /110v co2 laser power supply power source for 80w 1600mm tube laser engraving and cutting machine. Get Discount Now! Only US $100.30/piece at this time. Hurry buy Now before back to normal price! Normal price US $118.00 or you can Check price now. Dont waste your time. Buy Now only in Shenzhen SolarMy Laser Store Trusted Seller Store!

80W CO2 Laser Power Supply for CO2 Laser Engraving Cutting Machine HY-T8080W Power Supply for C0₂ Laser TubesModel: HY-T80 Description:Model: HY-T80 for 80w Co2 Laser Tubes Alias: Co2 Laser Generator, Co2 Laser Source,Co2 Laser Device,High Voltage Power Supply Application:HY-T80 Laser Power Supply is used for 60W,80W Cutting and Engraving Acrylic, Fabric, Double Color Sheet and Rubber,ect.80w Laser Power Supply Main Features:1) Good compatibility: It can be applicable to 80W laser tube of a number of manufacturers.2) Cutting Type and Sculpting Type: The cutting type has a good power stability and strong adaptability; while the sculpting type has a quick response speed and good engraving effect.3) Dramatically lengthen the service life of laser.4) Easy Control: The start and stop of laser can be easily controlled by TTL level. And there are protection switch to test the external water, ventilation, etc.5) Easy control of laser power: Both 0-5V analog signal and PWM signal can control the laser power.6) The power supply has the function of open circuit protection: Under the condition of good protective earthing, the power supply can work in open-circuit condition for a short time, which could avoid the damage of laser power supply because of the bursting of laser tube, thereby enhancing the life of power supply.7) The power supply can take feedback interface which can be used in closed-loop control and testing the working current of laser.8) The power supply adds a new function, that is timely scene judging which part is damaged, laser tube or laser power.9) Application: Acrylic sculpture, cut; fabric sculpture, cut; Double-color plate engraving, cut; rubber sheet sculpture, cut, etc.HY-T80 High Voltage Power Supply Specification

AC220V or AC110V

	AC Frequency	47-440Hz
	Cold surge current	≤60A(AC220V input)	≤60A(AC220V input)
	Leak current	≤0.7mA(AC220V input)	≤0.7mA(AC220V input)
Output	Max output Voltage	DC 40KV
	Max Output current	DC 28mA
Efficiency	when≤92%load down
Time no-failure	≤10000 hours
Response speed	≤1ms(the time from output of switch signal to 90%of initial setting current)
Control port	TLL electricity level switch control, valid electricity has high/low level choices
Volage-resisting	Input-Output ,input-machine hull: 1500V 10mA 60s AC output cathode and machine hull connection
Protection	Can be used an opening way in a short time request the outer shell be good to connect the ground avoid arcing between anode and machine hull connection in the machine
Vsage environment	Work temperatur(-10-40) Relative humidity≤90%
Cooling Type	The compuisive air cooling
size	L×W×H=210×160×95mm
Weight	4kg

Notice: Please leave us message 110V or 220V is needed when place the order, thanks!

​

Connection way between power supply and co2 laser glass tube
