Popular Laser Choice Product provide 3d laser,laser flashlight,laser led,laser meter,laser pointer Super Promo 10% off Discount !Komshine GX36 FTTH Fusion Splicer Kit w/ KF-52 Fiber Cleaver+SM 1550nm OTDR+Power Meter+Laser Source+ VFL. Price at this time US $2385.00/piece. Check price now to get discount! Dont waste your time. Buy Now only in Fiber Optic Resale Corp Trusted Seller Store!
Simply as you will certainly obtain a ton of money, this item is able to offer a vehicle that should be really intriguing for you. The goods directory you get is definitely offer a recommendation for those of you who want to find the goods you want.
KomShine Optical Fiber OTDR equal to EXFO MAX-715B,JDSU MTS-2000,MTS-4000,YOKOGAWA AQ7275 OTDR PriShips in 24Hrs via TNT/DHL/Fedex, Get it Fast
ORIENTEK T37 Fusion Splicer Kit w/ Cleaver + ORIENTEK T303 Single Wavelength 1550nm 30dB OTDR + Optical Power Meter + Optical Light Source + Visual Fault Locator
Brand New!
All the items come with 1-Year-Warranty
All the items come fully Calibrated
1: Komshine GX36 FUSION SPLICER KIT INCLUDES:
• Komshine GX36 Fusion Splicer
• High Precision Cleaver integrated Scrap Catcher
• High Precision Fiber Stripper
• Battery Built-in
• AC Adapter/battery charger
• Power Cable
• Spare Electrodes
• Carrying Case
• Cooling Tray
• Fusion Splice Protection Sleeves 100pcs
• 1 Year Warranty
* Built-in Universal Fiber Holder which can Splice 250μm fiber, 900μm fiber, flat cable, and fiber jumper. *
Tech1: 8800mAH high capacity replaceable battery to extend your productivity
Tech2: 6 Motors 3 Axle alignment make lower loss
Tech3: Reliability and Durability: Anti-Shock, Waterproof, Dustproof
* Ships in 24 Hours via Fedex express *
-- Come With Calibration Certificate and Test Report-- Come With 1-Year-Warranty
-- Come With the NEW Fiber Cleaver
-- Come With 100pcs 60mm FPS Fusion Splice Protection Sleeves
Specification:
Applicable Fibers | SM / MM / DS / NZDS / BIF & UBIF (G.657) |
Average Loss | 0.02dB(SM) / 0.01dB(MM) / 0.04dB(DS) / 0.04dB(NZDS) / 0.02dB(G.657) |
Return Loss | >60dB |
Operation Methods | Auto, Manual |
Typical Splicing Time | 9s |
Typical Heating Time | 28s |
Fiber Alignment | Core Alignment / Clad Alignment |
Fiber Diameter | Cladding: 80~150 um / Coating: 100~1000 um |
Cutting Length | 8~16mm(Fiber diameter: <250um) / 16mm(Fiber diameter: 250~1000um) |
Magnification | X or Y: 310X / X + Y: 155X |
LCD Display | High performance 3.7 inch. TFT LCD / 640x480 resolution |
Tension Test | 2N |
Applicable Sleeve | 60mm / 40mm / 20mm or etc. |
Battery Capacity | Average:200 cycles (Splicing and Heating) Charging time: 3 hours |
Battery Life Cycle | 300~500 charge / discharge cycles |
Electrode Life Cycle | Typical 3000 times |
Power | Removable battery : 11.1V 8800mAH AC/DC adapter: input:AC100-240V output:DC13.5V/5.0A |
Working Environments | Temp: -10C~+50C Humidity: 95%RH Elevation: 0~5000M |
Dimension | L×W×H=135×160×150(mm) |
Weight | 1.8 KGs (without battery), 2.3 KGs (with battery) |
2:
Komshine QX30 Single Wavelength 1550nm 30dB SM OTDR With FC/UPC Connectors INCLUDES:
* Color Display with Touch Screen ** Ships in 24 Hours via Fedex express *
* Come with FC Adaptors *
* English Languages *
* Test Results Analysis Softeware *
Specifications:
| Model | = | QX30 |
| Wavelength(nm) | = | 1550 |
| Dynamic range(dB) | = | 30 |
| Pulse width (ns) | = | 5,20,40,80,160,320,640,1280,2560,5120,10240,20480 |
| Display | 3.5 inch TFT LCD touch screen | |
| Event blind zone (m) | = | 8 |
| Attenuation blind zone (m) | = | 10 |
| Linearity (dB/dB) | = | ±0.05 dB/ dB |
| Loss threshold (dB) | = | 0.05 |
| Loss resolution ratio (dB) | = | 0.01 |
| Sampling resolution ratio (m) | = | 0.125 to 8 |
| Sampling point | = | 32k |
| Distance uncertainty (m) | = | ±(1 m + 5×10-5× distance + sampling interval) |
| Distance scope (km) | = | 0.3 to180 |
| Memory capacity of trace | = | SD Card (4G), > 10000 pieces |
| Duration of measurement | = | Defined by user; 5sec, 10sec, 15sec, 30sec, 1min, 2min, and 3min are selectable |
| Optical interface | = | FC/UPC+SC/UPC+LC/UPC |
| Data interface | = | USB interface, SD card interface |
| Visual Fault Locator | = | NON |
| Power supply | = | Lithium battery; continuing working duration ≥ 8 hours |
| Warranty period | = | 12 months |
Standard Package:
T303 OTDR
FC+SC+LC UPC Connectors
SM Fiber Optic Patch Cord FC-SC 1M
Testing & Calibration Report
AC/DC adapter
Quality certification
Trace analyzing software(CD)
Internal Battery
User Manual
Carrying Case
3: Mini Optical Power Meter + Mini Light Source + Visual Fault Locator INCLUDES:
- 1. Six wavelenghts Optical Power Meter for SM & MM
- 2. Dual Wavelengths 1310/1550nm Optical Light Source for SM
- 3. Pocket size Visual Fault Locator
- 1 Year Manufacturers Warranty
