Hurry! Deals LCDA86H+LC86H298 20-70VAC/30~100VDC 2PH 6A 7.2NM NEMA34 86mm DSP Closed-Loop Step Motor Drive Kit for Laser Machine

Hurry! Deals LCDA86H+LC86H298 20-70VAC/30~100VDC 2PH 6A 7.2NM NEMA34 86mm DSP Closed-Loop Step Motor Drive Kit for Laser Machine Rating: 2.6 out of 5

Laser Machine Best Choice Product provide laser cnc,laser engraving machine,laser machine,laser printer,laser wood machine Hurry! Deals LCDA86H+LC86H298 20-70VAC/30~100VDC 2PH 6A 7.2NM NEMA34 86mm DSP Closed-Loop Step Motor Drive Kit for Laser Machine. Price at this time US $122.00/piece. Check price now to get discount! Dont waste your time. Buy Now only in EX-press shopping Store Trusted Seller Store!

Great New Hurry! Deals LCDA86H+LC86H298 20-70VAC/30~100VDC 2PH 6A 7.2NM NEMA34 86mm DSP Closed-Loop Step Motor Drive Kit for Laser Machine product could enhance the quality of your life. Qualified to be bought. Low-cost cost and also totally free delivery. Let's purchase before prices increase.

LCDA86H+LC86H298 20-70VAC/30~100VDC 2PH 6A 7.2NM NEMA34 86mm DSP Closed-Loop Step Motor Drive Kit for Laser Machine

Package:

1. motor LC86H298

2. drive LCDA86H

3. Encoder cable& Power Cable

Motor Electrical Specifications

Model

Phase

Holding

torque

Phase

current

Motor

Length

rotational inertia

Weight

kg

Encoder

ppr

LC86H260

2

3Nm

6A

60mm

1.1g.m2

2

1000

LC86H268

2

3.6Nm

6A

68mm

1.4 g.m2

2.2

1000

LC86H280

2

4.5NM

6A

80mm

1.8 g.m2

2.5

1000

LC86H298

2

7.2NM

6A

98mm

2.8g.m2

3.3

1000

LC86H2120

2

8.5NM

6A

120mm

3.6 g.m2

4

1000

LC86H2128

2

10.5NM

7.5A

128mm

4.2 g.m2

4.5

1000

LC86H2160

2

12nm

7.5A

160mm

5.4 g.m2

5.4

1000

Drive functional characteristics

Model

LCDA86H

working voltage

20-70VAC/30~100VDC

peak current

6A

control mode

32 bits DSP closed-loop vector control technology

Pulse limit frequency

Defaulting 200 KHZ/500 KHZ (optional)

defensive function

Over-current, over-voltage and tracking error out-of-tolerance alarm

incoming signal

Pulses, direction and enable signal

outcoming signal

In position signal and fault output signal

motor encoder feedback

AB differential input

subdivisions

The default 4000/rev, through debugging software can install arbitrarily subdivisions (200-51200)

storage temperature

-20-80 degree centigrade

Ambient Temp

0-50 degree centigrade

Ambient thumidity

40-90RH

parameter setting

Static current, subdivisions, effective along, fault signal output signal level, position loop and current loop and parameter settings.

Application:

It is suitable all kinds of Small and medium-sized automation equipment and instrumentation.

Such as carving machine, wire-stripping machine, marking machine, cutting machine, laser machine, plotting instrument, medical equipment, CNC, etc. This is efficient for the equipment with Low noise and high-speed.
